Beschreibung
A small footprint vertical curing oven with a single column requiring less than 4 feet of cleanroom space.
Technische Daten
| VCO755 K3/K5 | VCO755 K3/K5-19 | VCO755 K3/K5-38 | |
| # Shelves | 54 up / 54 down | 36 up / 36 down | 18 up / 18 down |
| Shelf Pitch (mm) | 12.7 | 19.05 | 38.1 |
| Max Board Capacity | 108 | 72 | 36 |
| Max Board Size LxWxH (mm) | 292 x 120 x 9 | 292 x 120 x 14 | 240 x 180 x 30 |
Anlagenmerkmale
- Oven Size (mm): 1874(L) x 1150(W) x 2256(H)
- Single Column, 2 Heated Zones
- 22 Tray Capacity (22 Up + 0 Down)
- Shelf Pitch 38.1mm
- Cure Time: Up to 60 minutes
- Max Zone Temperature Set Point: 120°C
- Exhaust Monitoring
Bilder
