Beschreibung
The 2156 MK7 17 reflow oven is a high volume reflow oven system with 17 heated zones and belt speeds up to 1.88m/min. The 2156 MK7 offers the lowest delta T’s, reduced nitrogen and electrical consumption and advanced flux management options. The 12” wide heater modules offer profile compatibility with competitor systems.
Technische Daten
| Reflow Oven Length | 869 cm (342″) |
| Process Gas Options | Air, Nitrogen |
| Heated Zones | Convection: 10 Top / 10 Bottom |
| Cool Zones | 5 Top (Bottom Option) |
| Max Working Temperature | Standard: 350°C (Option: 400°C) |
| Maximum PCB Width | 55.9cm (22”) |
| Cleanroom Option | Down to Class 1000 |
Anlagenmerkmale
- Built-in Thermal Monitoring
- Nitrogen Capable to < 100 ppm
- Energy Management System
- Virtually No Maintenance
- 12” Wide Heater Modules
